DX5 Eco-solvent Print Head

The Epson DX5 solvent printhead is used by various__Chinese solvent printers. This DX5 printhead allows fast speed, high resolution printing with eco-solvent or light solvent inks. The Epson DX5 original printhead is delivered in a sealed Epson package.

This DX5 printhead model is compatible with all DX5__based Chinese printers and requires no decoder This is the original Epson DX5 printhead, not modified or coded. It corresponds to F186000, F1440-A1 or FA26002-0030.

This printhead should not be used in Mutoh Valuejet or__Mimaki JV33 / JV5 printers as it has different voltages and therefore offers a different image quality. DF-49684 and PPHMIJV5006 should be used in Mutoh and Mimaki printers.

The following items are expressly__excluded from warranty coverage:
Errors related to the use of non-original inks, by any means
Clogged, missing or deviated nozzles
Defects related to abuse, misuse, accident, neglect, lack of use, or improper__storage when not in use for extended periods of time.
defects related to failure to perform periodic maintenance specified in user__documentation; Operation for unintended purposes
Error related to improper loading of media
All other defects, failures or damages are not considered manufacturing defects
DEFECTS RELATING TO THIRD-PARTY APPLICATIONS, SOFTWARE, PARTS, COMPONENTS OR PERIPHERAL__DEVICES, INCLUDING ANY BULK INK SYSTEM.
Defects which are merely cosmetic in nature.

Product details

Technology: Micro-piezo
Native resolution: 1440 dpi
Min. Droplet size: 1.5 picoliters
Maximum droplet size: 21 picoliters
Quantity of Tote Nozzles: 1440 (8 lines x 180 nozzles)
Firing frequency: 8 kHz
Ink compatibility: solvent and eco-solvent based
This printhead carries a manufacturer’s warranty.
Country of origin: Japan

We recommend changing__the head cables when installing a new printhead.
